New Cheap Portable Mini Fiber Color Pigeon Ring Laser Marking
Machine Plastic Tag Engraver Machine
Hot Sale 20W 30W 50W fiber laser marking machine portable or
desktop type
(Marking Area:110*110mm,175*175mm optional)
Applicable Industries of fiber laser marking machine:
Mobile Phone keypad,plastic translucent keys,electronics
components,integrated circuits (IC),electrical
appliances,communications products,sanitary
ware,tools,accessories,knives,eyeglasses and clocks,jewelry,
auto parts,luggage buckle,cooking itensiles,stainless steel
products and other industries.
Applicable Materials of fiber laser marking machine:
Metal(including rare metals),engineering plastics,electroplating
materials,coating material,plastic,rubber,
epoxy resin,ceramic,plastic,ABS,PVC,PES,steel,copper and other
materials
Product Description:
Plastic safety sealer laser printer, especially suitable for laser
engraving and metal laser marking. Lasers can be used not only to
accurately and clearly mark non-metallic materials such as
plastics, but also to mark very hard alloys. For some plastic
products, such as PP, ABS, MPP, etc., from the industrial
production of product marking to traceability, to the
personalization of promotional items with logos or names, the
application is very wide.
Applicable Material:
Laser marking machine can work with most metal marking
applications, such as Gold, Silver, Stainless Steel, Brass,
Aluminum, Steel, Iron etc, and can also mark on many non-metal
materials, such as ABS, Nylon, PES, PVC, Makrolon.
Applicable Industry:
1. Mechanical Parts: Bearings, Gears, Standard Parts, Motor, etc
2. Instrument: Panel Board, Nameplates, Precision equipment, etc.
3. Daily Necessities: Handicrafts, Zipper, Key Holder, Sanitary
Ware, etc.
4. Hardware Tools: Knives, Tools, Measuring Tools, Cutting Tools,
etc.
5. Automobile Parts: Pistons and Rings, Gears, Shafts, Bearings,
Clutch, Lights, etc.
6. Electronic Components: Resistors, Capacitors, Chips, Printed
Circuit Boards, Computer Keyboard, etc.
Technical Parameters:
| Name and Number | KY-M-FB20 |
| ModelLaser Characteristics |
| Power | 20W |
| Laser wavelength | 1064nm |
| Spot Diameter | 7.0±1.0mm |
| Beam Quality(M²) | ＜1.2 |
| Mode Quality | ≧98%TEM00 |
| Modulation Frequency | 1-1000(KHZ) |
| Max. Single Pulse Engergy | 1mJ |
| Power Stability(8h) | ＜±1﹪ms |
| Marking Parameters |
| Marking Size | 110mm*110mm, 150mm*150mm, 200*200mm (others for optinal) |
| Marking Speed | 0-11000mm/s |
| Marking depth / Roman Type , Character Height 1mm | 0.01-2mm( Depending on the material ) |
| Marking Content/ Character Types | Text/letters/numbers/symbols/graphics/design/logo, etc.
Date/time/QR code / Barcode/ batch number/serial number, etc.
real-time number coding |
| Min. Spot Size | 0.02mm |
| Precision | ±0.003mm |
| Other Information |
| System Protection Rating | IP54 |
| Cooling | Air Cooling |
| Operating Environment Requirements | Temp.:8℃-40℃; Relative humidity≤95%RH； Air
dust≤0.01g/m³；Atmospheric pressure ≤86—106Kpa |
| Power Supply | 220V±5%,50Hz±5% Single-phase AC power suppl |
| Power Consumption | <0.5KW |
Sample Picture:
Package:
