50w CO2 Laser Marking Machine For Non Metal Materials 1064nm Laser Wavelength

Ask Lasest Price
Brand Name :	keyi
Model Number :	KY-M-CM
Certification :	CE
Price :	negotiate
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	2000 per month
Delivery Time :	5-7 working days

Add to Cart

Product Details
Company Profile

50w CO2 Laser Marking Machine For Non Metal Materials 1064nm Laser Wavelength

co2 laser marking machine for non metal materials / laser marking machine

Machine description:

CO2 Non-metallic laser marking machine is controlled by the computer, can mark on the surface of processing materials along the desired track through 10.64um laser beam’s beam expanding, focus, galvanometer’s deflection to achieve the engraving effect. The non-metallic laser marking machine made by our company has good beam mode, stable system performance, free maintenance, is suitable for the large quantity, multispecies, high speed, high precision and continuous production in the industrial site.

Machine features :

1. High speed , equipped with good galvanometer;

2. Small volume ,light weight;

3. Low power, consumption power is less than 500w

4. Completely air cooling ,low energy;

5. No influence of the severe environment and temperature change. If no power, battery and car cigarette lighter can be used for working;

6. Greatly reduce the depreciation cost, satisfying customers' stable large quantity producing.

Parameters co2 marking laser

NO. Model :KY-M-CM
Laser Power	50w/80w
Working Area	110110mm/200200mm/300*300mm
Cooling Mode	Water Cooling
Laser Wavelength	10.64um
Response Time	0.5ms
Frequency of pulse	20-100KHz
Marking Depth	≤0.4mm
Marking Speed	≤8000mm/s
Marking Lines	1-10 lines
Minimum Line Width	0.01mm
Minimum Character	0.15mm
Repeatability Accuracy	±0.002mm
Resolution Ratio	0.1mm
Marking Content	Text, pattern, date, bar code, etc
Operation System	Microsoft Windows7 10
Control Software	EZCAD Control Software
Graphic Format Supported	BMP, JPG, GIF, TGA, Ai, DXF, PLT, PNG, TIF, ai, DXF, DST, etc.
Unit Power	≤1.2KW
Operation Temperature	5°C-40°C
Relative Moisture	≤ 90%, no fog
Supply Voltage	220V/50Hz/1phase
