Mini PCB Laser Printer 3W 5W 15W CO2 UV Laser Marking Machine

1. Product Introduction
Two laser heads to mark on both sides of PCB, load and unload the plate with vacuum sucker in two feeding line.
CT:500mm×500mm PCB, marking on both side, 2 marks on each side,4 seconds per PCB.

2. Technical Feature
Two workplaces switching mode,and to mark on both sides at same time with two laser heads.
Vacuum sucker does no demage to PCB plate.
Device size: 2300mm*1900mm*1600mm.

Laser Source: CO2/Fiber/Green/UV
Vision System: CCD Positioning, Code Checking
Platform: high precision linear motion module, conveyer track.
Automation: Conveyer width adjustable; electric focusing system optional.
Auxiliary Device: Deduster
Communication Protocol: Standard SMEMA Interface

Marking Size: 50X50mm~460X510mm (Default Size. Customize able)
PCB thickness: 0.3mm~5mm
Marking Precision: ±0.1mm
Minimum Beam Dia.: 100um
Device Size: 1000mm(W)×1600mm(D)×1500mm(H)
Conveyer Height: 870mm-930mm (Default height. Customize able)
Conveyer Running Direction: L-R/R-L
